Unicorn TT-22-20 – Technical Specifications

General Information

• Brand: Unicorn

• Product Model: TT-22-20

• Weight: 1200 kg

• Dimensions: 3100 mm (L) × 1100 mm (W) × 1500 mm (H)

Performance

• Theoretical Throughput: 10–12 m³/h

• Theoretical Transmission Distance: 80–100 m

• Theoretical Transmission Height: 50 m

• Bone Diameter: ≤ 25 mm

Power & Mechanism

• Maximum Pressure: 14 MPa

• Cylinder Diameter × Stroke: 120 × 580 mm

• Motor Power: 22 kW

• Oil Pump Power: 63 (Gear) U/S

• Conveying Pipe Diameter: Φ80 mm

Included Attachments

• Φ80 Iron Pipe – 30 meters

• Transparent Hose – 10 meters (1 pc)

• Φ80 Cards – 13 pcs

• 100 Cards – 1 pc

• 90° Elbows – 2 pcs

• 100–80 Reduction – 1 pc

• 45° Elbow – 1 pc

• Hose Connector – 1 set

• Toolbox – 1 set
