UNI 40 B Bar Bending Machine

The UNI 40 B is a compact and reliable bar bending machine designed for efficient and precise bending of reinforcement bars in construction and infrastructure projects. Built with a durable copper winding brake motor and robust body structure, it offers consistent performance for small to medium-scale operations.

Key Features:

• Bar Bending Capacity: 6 mm to 32 mm diameter rebars

• Operation: Fully automatic for ease of use and productivity

• Motor Type: Copper winding with brake motor for enhanced safety and durability

• Motor Power: 3.7 KW / 4 HP

• Phase: Three-phase connection

• Motor Speed: 1440 RPM for smooth operation

• Voltage: 415V

• Production Capacity: Up to 2 Tons per hour

• Machine Weight: Approx. 320–330 Kg (based on build)

• Dimensions: Approx. 850×800×880 mm

Applications:
Ideal for use in construction sites, civil engineering projects, and precast concrete yards where medium-scale bending is required with speed and accuracy.
